First test of JTS domed pellets

This report covers:

  • The test
  • BB’s Goldie
  • Drum roll!
  • S510XS
  • Good result
  • Where made?
  • What kind of lead?
  • Uniformity
  • Summary

Today I begin both accuracy and uniformity testing of the JTS pellets that we discussed yesterday. There is one more factor to consider than I brought up yesterday and I’ll cover it next

The test

I shot from a sandbag rest at 25 yards. I shot BB’s Goldie and my Air Arms S510XS. For each rifle I went back and found the most accurate pellet and shot it as a baseline group.

I shot 10-shot groups. Had I stopped at 5 shots there would have been one group that measured 0.0-inches between centers — or at least it sure looked that way through the scope.

All pellets were shot straight out of the tin; there was no sorting. I shot BB’s Goldie with a single-shot tray because that is how it does its best. The S510 does best with the 10-shot rotary magazine, so that’s how I shot it.

The additional factor in today’s test is me. Some days I’m hot, others I’m not. Today was a lukewarm day. Since I’m touching the rifles I’m a variable, too.

I filled both rifles full after verifying their respective fill pressures. Everything was as close to the same as I could make it. I have made a number of mistakes in the recent past from being confused about the technical specs of the airguns I test. I wanted today to go without a hitch.

BB’s Goldie

The first rifle to be shoot was BB’s Goldie. It shoots both Air Arms 16-grain domes and JSB Exact Monster Redesigned pellets very well so I chose the Monster Redesigned. These are the older Redesigned pellets with the thinner skirts and this rifle loves them. I will say, though, that they load harder than many others. That’s a head size thing, I think.

Ten pellets went into a group that measures 0.262-inches between centers of the two pellets farthest apart. I saw that the group was high but since I was going to shoot different pellets I decided not to touch the scope adjustments.

Goldie Redesigned
BB’s Goldie put 10 JSB Monster Redesigned pellets into a 0.262-inch group at 25 yards.

That’s a good start. Now we know at what level I am shooting today. I’ve done better; I’ve done worse.

Drum roll!

Here it comes. This is the first test of the JTS .22-caliber domed pellet. And, by the way, this pellet does not disassemble, which is what Take Down (written on the tin) means. I assume the maker meant that it is good on game. That would be Takedown — one word instead of two.

Ten JTS Dead Center domed pellets went into a group measuring 0.172-inches between centers. That’s right — JTS outshot JSB. And BB can still shoot! This is the smallest group of today’s test and it is also the group wherein the first 6 shots were in 0.0-inches between centers. These pellets also loaded harder in BB’s Goldie. Again, I think it’s the head size.

Goldie JTS
BB’s Goldie put ten JTS Dead Center domed pellets into a 0.172-inch group at 25 yards.

S510XS

Now I shifted over to the Air Arms S510XS rifle. This one likes them loaded through the magazine so that’s how I did it. It also likes Air Arms 16-grain domes and JSB Monster Redesigned pellets. Go figure. I feel the Air Arms 16-grainers have a slight edge in this rifle, so that’s what I shot.

Ten Air Arms 16-grain domes went into a group that measures 0.394-inches between centers. This is one of the larger groups I have shot with this rifle and pellet, but hey — this is a test. And please note that the center dot of the bull was blown away, so I had to guess where to aim for the last 6 shots. I’ve done pretty good doing that in the recent past, but I’m just sayin’ that’s what happened.

S510 AA16
The Air Arms S510XS put ten Air Arms 16-grain domes into a 0.394-inch group at 25 yards.

Now it’s time for the JTS pellets. The S510XS put ten of them into a 0.245-inch group at 25 yards. This time I didn’t quite blow away all of the center dot, so there was something left at which to aim.

S510 JTS
The Air Arms S510XS put ten JTS domed pellets into a 0.245-inch group at 25 yards.

Build a Custom Airgun

Good result

Today’s results are good, no doubt about it. But more testing is needed. Two 10-shot groups are hardly conclusive.

Where made?

These pellets are made in China. Are they a rebranded pellet made by someone else? No. I have been told they are brand new and that a whole line of them is coming.

Will the quality remain high? How do I know? I don’t have a crystal ball to see into the future. But I will say that this is a great start.

What kind of lead?

I was asked how hard the lead is. I have no way of knowing that precisely, but using the muzzleloader’s trick of a thumbnail I will say it is very soft. Is it as soft as JSB? No way for me to tell.

Uniformity

Here we go. I weighed 10 random pellets and this is what I got.

Pellet……weight in grains
1…………..………18.2
2…………………..18.1
3…………………..18.1
4…………………..18.0
5…………………..18.1
6…………………..18.1
7…………………..18.1
8…………………..17.9
9…………………..18.1
10…………………18.1

Then I checked 10 head sizes, again with random pellets and not the same ones as were used for the weight. I used the Pelletgage for this.

Pellet……head size in mm
1…………………..5.52
2…………………..5.53
3…………………..5.53
4…………………..5.52
5…………………..5.53
6…………………..5.53
7…………………..5.52
8…………………..5.53
9…………………..5.52
10…………………5.53

For those who aren’t sure, both of these results are very uniform. This is a JSB level of uniformity.

Summary

I can’t say for certain yet how good these JTS pellets are, but today’s results leave me very encouraged. Remember what I said yesterday about what if these were JSB-level pellets? Well, so far, they are.
