STUD Magazine for FX Impact, .30 (7.62mm)

Be the first to review!
STUD Magazine for FX Impact, .30 (7.62mm)

STUD Magazine for, Image 1STUD Magazine for, Image 2
youTube video

See other products by STUD Loading Solutions

  • Fits the STUD Loader/Feeder system
  • Visual "Shots Remaining" indicator
  • Magnetic Lid, no twisting of knobs
  • Custom wound coil spring (no adjustments required)
  • Roller bearing for smooth feeding
  • Pellets or slugs up to 12mm (.472") in length

Existing owners of STUD Loaders/Feeders for the FX Impact: In most calibers we manufacture several different round counts of STUD Loaders/Feeders and DTM's. This is because FX has made several changes to their Impact mag round counts recently. For example, the .25 factory mag is/was made in 23, 25 and 28 rounds. We have standardized on the round counts for our new magazines that we know works best for you. You need to understand that the round counts of the STUD "factory replacement" magazines may not match your existing STUD Loader/Feeder system. If you still want the "automatic" benefits of the STUD loading System, you will need to order a STUD Bundle that matches our magazine round counts. The caliber/round counts for the new STUD Magazines are: .177 x 34 rounds, .22 x 28 rounds, .25 x 25 rounds, .30 x 21 rounds and .35 x 18 rounds. ** Existing owners of STUD DTM's for the FX Impact ** The new STUD magazines will not fit the old DTM's (shipped before 9/1/22) because of the new magazine's lid system has features that will interfere with fitting the mag to the old DTM's. You can ship your old DTM to STUD for a no charge modification (we mill out a clearance area next the locating pin).



STUD replacement magazines for the FX Impact are a highly engineered aftermarket magazine that will enhance one of the most important and repetitive aspects of shooting. Here is what makes STUD magazines so special:

They work with Slugs and Pellets, even the heavy ones! A taller center rotor with improved drive spring provides the clearance and power needed to handle slugs up to 12mm (.472) in length. STUD magazines not only correctly index these larger rounds but do so reliably.

Our "remaining rounds" indicator clearly shows the rounds remaining in the magazine. A special colored circle on the "stop slug" allows you to quickly identify the number of rounds remaining.

We have gone a step further to provide you with the best magazine available by including a class 2RS ball bearing in the main rotor. This provides an incredibly stable and precise movement and enhances the positioning of the rounds for added accuracy.

Finally our magnetic easy  on/off lid takes the work out of your reloads. The magnets are strong enough to keep the lid on even with heavy slugs ensuring they do not dislodge while making the center locking process easy on your fingers.

BECAUSE FX HAS MADE SEVERAL IN-LINE CHANGES TO THE FX IMPACT AND IT'S MAGAZINE SYSTEM PLEASE READ THE FOLLOWING CAREFULLY.

Existing owners of STUD Loaders/Feeders for the FX Impact:

In most calibers we manufacture several different round counts of STUD Loaders/Feeders and DTM's. This is because FX has made several changes to their Impact mag round counts recently. For example, the .25 factory mag is/was made in 23, 25 and 28 rounds.

We have standardized on the round counts for our new magazines that we know works best for you. You need to understand that the round counts of the STUD "factory replacement" magazines may not match your existing STUD Loader/Feeder system. If you still want the "automatic" benefits of the STUD loading System, you will need to order a STUD Bundle that matches our magazine round counts.

The caliber/round counts for the new STUD Magazines are: .177 x 34 rounds, .22 x 28 rounds, .25 x 25 rounds, .30 x 21 rounds and .35 x 18 rounds.

** Existing owners of STUD DTM's for the FX Impact **

The new STUD magazines will not fit the old DTM's (shipped before 9/1/22) because of the new magazine's lid system has features that will interfere with fitting the mag to the old DTM's. You can ship your old DTM to STUD for a no charge modification (we mill out a clearance area next the locating pin).

This item is not eligible for coupon discounts


See other products by STUD Loading Solutions

Specs

Caliber.30 (7.62mm)
Weight1.0 lbs
StyleMagazine Only
