PY-A-5905

Air Venturi Wingman 98, 98 cu ft PCP tank

4.5 (18 reviews) Review, article, latest buzz
Air Venturi Wingman 98, 98 cu ft PCP tank

Air Venturi Wingman, Image 1Air Venturi Wingman, Image 2Air Venturi Wingman, Image 3Air Venturi Wingman, Image 4Air Venturi Wingman, Image 5Air Venturi Wingman, Image 6

Share your images

$699.99

List Price $849.99

Pick Your Option
  • 1-year limited warranty

  • 60 day money back guarantee
  • Estimate Shipping

Add to Compare
Add to Wish list

Excluded from coupons

Earn 700 Bullseye Bucks

Add to Cart

In-stock


Sold & shipped by PyramydAir


  • FeatureIcon
    Made in the USA.
youTube video

See other products by Air Venturi

See manual
Share
Item details

Sold & shipped by PyramydAir


Air Venturi Wingman Price

$699.99

Air Venturi Carbon Fiber PCP Charging Station



Assembly includes:

  • 98 cu. ft. carbon fiber tank, 4,500 psi
  • DIN 300 bar PCP charging station
  • DIN 300 bar valve with burst disc
  • Inline pressure gauge 0-6000 psi 1/8" BSPP



Charging Station:

  • 4,500 psi max pressure
  • 24 in. microbore hose with 1/8" BSPP
  • Male and female threaded ends, each 1/8" BSPP
  • Stainless steel female quick-disconnect coupling attached to output end of hose
  • Includes test plug for checking pressure remaining in the tank



Specifications:

  • Carbon fiber filament wound over aluminum bladder
  • 98 cu. ft. air capacity
  • 4,500 psi max pressure
  • DOT-approved / DOT-SP 11194
  • 13 lbs. dry weight
  • 7.5" wide
  • 25" tall to top of valve
  • Empty weight 12.95 lbs
  • Filled weight 19.1 lbs





One of the largest charging tanks available in the marketplace, the Air Venturi Carbon Fiber Charging Tank weighs much less than a steel scuba tank. Better yet, the advantage of carbon fiber over steel allows for a higher pressure capability of 4,500 psi, meaning more charges for your favorite PCP airgun and more shooting time for you.

Fill your air rifles and pistols with the simple fittings and be on your way to more pest control, target shooting and even competition. With 4,500 psi and a whopping 98 cu. ft. capacity, enjoy the most refills of your 3,000 psi airguns. The tank features stainless steel fittings, a 24 in. microbore hose and a rubberized hand wheel for controlled filling. The integrated pressure gauge lets you know when you're reaching your full charge, and the bleed valve is conveniently located on the valve.

Even shooting teams will be delighted at the number of fills they get from the Air Venturi Carbon Fiber PCP Charging Station. Averaging more than 40 fills, this tank is a practical choice for many shooting venues. For example, approximately 42 charges are provided on a 3,000 psi gun with a 215cc cylinder from a beginning gun reservoir pressure of 1,500 psi. You can expect more than 20 full charges on empty 3,000 psi gun with a 215cc cylinder. (The total number of fills vary based on the maximum charging capacity and the reservoir size of the gun(s) being charged.)

Comes with Jubilee Gun Charging Valve that incorporates a patented device restricting the flow rate into the airgun.

This tank has a 5-year retest cycle and a 15-year life cycle.

This compressor features an in-line gauge that shows the pressure in the line as you are refilling the tank, which is helpful to prevent overfilling.  This gauge does NOT show internal pressure! To check your internal pressure, plug the end of the hose with a test plug and open the valve with the bleeder fully closed.

Additionally, there may be a slight movement in gauge’s valve connection when not under pressure.  This is no cause for concern and will not cause any leaks or malfunctions in use.

Before purchase, please contact your local air supplier to see if they can fill this tank or buy one of our compressors.

This carbon fiber tank has a 300 bar DIN valve. Your local dive shop will have the ability to fill your tank.

If you plan on filling your high-pressure carbon fiber tank at a paintball shop, you will need to fill through the hose on the charging station with the Air Venturi Double Male Quick-Disconnect Coupling AV-00046 [PY-A-5202].

To fill at a firehouse, you will need to fill through the hose on the charging station with the Air Venturi Firehouse Adapter, Male SCBA Fitting With Male Quick-Disconnect For Adapting To Firehouse Fill Stations AV-00048M [PY-A-5750].

PLEASE NOTE: This is a carbon fiber tank. In many towns your local fire department has a compressor that can fill a high-pressure carbon fiber tank, as firefighters use similar tanks for breathing equipment during rescues.

The calculations below assume the 98 cu ft Wingman is filled to 4500 PSI. A "full fill" refers to the gun being refilled to the maximum operating pressure. It's important to understand that most rifles do not need to be filled to their max pressure to offer a good number of consistent, usable shots.

Airgun Max Fill Pressure Air Cylinder Size # of Full Fills
Air Arms S510 XS Carbine 3625 psi 186 cc 30 fills
Air Arms S510 XS Xtra 3625 psi 288 cc 19 fills
Air Force Aluminum Cylinders 3000 psi 490 cc 28 fills
Air Force Carbon Fiber Bottle 3625 psi 475 cc 10 fills
Air Venturi Avenger 4350 psi 180 cc 4 fills
Benjamin Marauder Rifle 3000 psi 215 cc 53 fills
FX Impact Compact 3625 psi 300 cc 14 fills
FX Crown MKII 3625 psi 480 cc 9 fills
FX Maverick Sniper 3625 psi 580 cc 7 fills
Umarex Gauntlet 3000 psi 213 cc 33 fills

In stock

This item is not eligible for coupon discounts


Item Code: AV-4598HPT [PY-A-5905]

See other products by Air Venturi

See manual
Share
Item details

Sold & shipped by PyramydAir


Air Venturi Wingman Price

$699.99

Specs

Weight13.0 lbs

Air Venturi Wingman Review

4.5 (18 reviews)
5 star
4 star
3 star
2 star
1 star
14 reviews
1 review
1 review
2 reviews

Create an online review

Customer images

Sort by Date: Newest–Oldest

5.0 5.0

4.0 4.0

Verified Purchase

Things I liked:

The light weight of the tank. Also the valves and overall quality seem really good.

Things I would have changed:

The whip hose is not the best. Like many, I replaced it with a braided hose. Also think long and hard about the size. A standard scuba tank is 80 cu.ft. This is larger than that. Many paintball shops cannot even fill this thing to 4500 PSI.

What others should know:

If you are new to air gunning like I was, the most important thing to know is that you only have two ways to fill this tank. 1) Take it to a pro dive shop or some higher end paintball shops to get filled. Maybe get in good with a local volunteer fire dept. 2) Spend an extra $1800-$3000 on a compressor that is rated with a high enough duty cycle and air piston volume to actually fill this thing. When I first got this I had some great dream that I was going to fill this with a $700 compressor. How wrong I was. Those $400-$900 compressors only have a duty cycle of around 15 minutes. At their flow rate - it will literally take 18+ hours to fill this. Well beyond what they are capable of. About the smallest compressor that can actually fill this in any reasonable amount of time will be something like the $1700 Air Venturi. After that, you are actually looking at things like semi commercial grade compressors designed for filling scuba tanks or SCBA tanks for firefighters.

5.0 5.0

5.0 5.0

Verified Purchase

Things I liked:

Tank size is great for extended shoot time. Makes for fewer trips to the compressor refilling the gun.

Things I would have changed:

About the only thing I would change is the hose. With tight fitting QD adapters the line tends to kink and the fitting. A steel braided line is a quick fix and really wouldn't add that much to the price.

What others should know:

The valve when fully charged can be a bit hard to turn in closing at first, but seems to wear in after a good number of refills.

5.0 5.0

5.0 5.0

Verified Purchase

Things I liked:

Having a tank has changed my PCP game, shooting is a lot more enjoyable

Things I would have changed:

I would add a base, it would make filling your rifle a lot more convenient if the tank could stand on end.

+ Load More

Got a question or answer?
Log in to participate

  • Edward from USA asked:

    Does the female connection from this tank attach directly to the male fitting of the air reservoir of the Benjamin Marauder PCP Air Rifle (P4-3139-6029) or is there another adapter required?

    • Victorino from USA asked:

      Whats the max pressure can be filled ? Usually take to the scuba diving shop and only get about 4-5 fills on my Fx Crown from 150-250 bars.

      • l2829tad from USA asked:

        Can this tank be connected directly to a Hatsan Blitz Full Auto to be used as the guns air "source" ? If so, How ?
